DB-16X Dual Band VHF/UHF 16 Channel Handheld Commercial Radio


Price:
$139.99

Shipping calculated at checkout

Stock:
Sold out

Description

Dual band VHF/UHF, 16 channel commercial transceiver, ideal for schools, restaurants, hotels and businesses. Pre-programmed with 16 channels. 2.5 KHz step for FCC narrowband. 1700mAH Li-ion battery. Part 90 certified. Model DB-16X replaces KG-UVA1X.

The DB-16X is a compact, high-performance dual band handheld commercial transceiver providing up to 5 Watts of RF power on VHF and 4 Watts on UHF, along with high audio output (500 mW).

Pre-programmed with 16 business channels. Ideal for security patrols, business communications, schools, construction crews, universities, and other organizations that have FCC licensed frequencies. FCC Part 90 certified.

Channel 1 464.5500 MHz 67.0 Tone 1W Business Ch. CLS-1 (Narrow 2.5 KHz)
Channel 2 467.9250 MHz 67.0 Tone 1W Business Ch. CLS-2 (Narrow 2.5 KHz)
Channel 3 467.8500 MHz 67.0 Tone 1W Business Ch. CLS-3 (Narrow 2.5 KHz)
Channel 4 467.8750 MHz 67.0 Tone 1W Business Ch. CLS-4 (Narrow 2.5 KHz)
Channel 5 469.5125 MHz 77.0 Tone 1W Business Ch. CLS-54 (Narrow 2.5 KHz)
Channel 6 466.3125 MHz 110.9 Tone 1W Business Ch. CLS-45 (Narrow 2.5 KHz)
Channel 7 466.3375 MHz 110.9 Tone 1W Business Ch. CLS-46 (Narrow 2.5 KHz)
Channel 8 466.3625 MHz 110.9 Tone 1W Business Ch. CLS-47 (Narrow 2.5 KHz)
Channel 9 467.7875 MHz 110.9 Tone 1W Business Ch. CLS-48 (Narrow 2.5 KHz)
Channel 10 467.8375 MHz 110.9 Tone 4W Business Ch. CLS-49 (Narrow 2.5 KHz)
Channel 11 467.8625 MHz 110.9 Tone 4W Business Ch. CLS-50 (Narrow 2.5 KHz)
Channel 12 467.8875 MHz 110.9 Tone 4W Business Ch. CLS-51 (Narrow 2.5 KHz)
Channel 13 467.9125 MHz 110.9 Tone 4W Business Ch. CLS-52 (Narrow 2.5 KHz)
Channel 14 469.4875 MHz 110.9 Tone 4W Business Ch. CLS-53 (Narrow 2.5 KHz)
Channel 15 154.570 MHz 88.5 Tone 1W VHF Business Ch. (Narrow 2.5 KHz)
Channel 16 154.600 MHz 88.5 Tone 1W VHF Business Ch. (Narrow 2.5 KHz)



Frequency Range of 136-174, 406-512 MHz RX/TX. FM: 76-108 MHz (RX). Software programmable via the optional low cost USB programming cable.

FCC Approval

The DB-16X is Part 90 certified for commercial use. CE & FCC Part 90 certified, FCC ID: WVTWOUXUN07

Powerwerx Warranty Policy

  • 12 month limited warranty on the radio against defects in materials and workmanship
  • 6 month limited warranty on the included radio battery and battery charger against defects in materials and workmanship

DB-16X Model Features

Standard Accessories Included with Every Radio

  • Dual band radio
  • Dual band antenna (4 inch rubber duck type with standard SMA connector)
  • Extended life 1700 mAh high capacity li-ion battery pack (16 hours of operation)
  • Intelligent desktop 3-4 hour rapid charger
  • Desktop charger AC power cord
  • Belt clip
  • Wrist strap
  • English user manual
  • Programming software (Free Download)

Features

  • Selectable high/low power settings (VHF: 5W high/1W low) (UHF: 4W high/1W low)
  • Includes extended life 1700 mAh high capacity li-ion battery as standard
  • Includes intelligent desktop 3-4 hour rapid charger
  • Loud speaker audio output (500 mW)
  • Bright flashlight illumination function
  • Meets IP55 waterproof rating
  • English voice prompts enable non-sighted operation (can be turned off)
  • 16 memory channels
  • Digital FM radio (76-108MHz)
  • Wide/narrow bandwidth selection (25 or 12.5 kHz)
  • Windows PC programmable, free software available for download. Optional low cost cable (SKU: WXUSB) required.
  • Radio to radio cloning with optional cable (SKU: WXCLN)
  • Same channel: VHF TX & UHF RX or UHF TX & VHF RX available
  • 105 groups DCS/50 groups CTCSS
  • CTCSS encode/Decode (no decode delay)
  • Low battery prompt
  • Busy channel lockout
  • Selectable time out timer (from 15 to 600 seconds)
  • Selectable step sizes of 2.5, 5, 6.25, 10, 12.5, 25, 50 or 100 kHz
  • Multiple scan modes
  • VOX Function (adjustable level)
Specifications DB-16X
Frequency Range RX/TX VHF: 136-174 MHz
UHF: 406-512 MHz
FM: 76-108 MHz (RX)
Memory Channels 16 channels (shared)
Operating Voltage 7.4 VDC
Operating Temperature -22°F to 140°F (-30°C to +60°C)

Dimensions

(W x H x D)

2.4 x 4.8 x 1.6 inches (61 x 121 x 39.5mm) (with 1700 mAh battery pack, without antenna)
RF Carrier Power VHF: 5W high/1W low, UHF: 4W high/1W low
Audio Output Power 500mW maximum
Waterproof Rating Meets IP55 waterproof rating
